In general, the CNC lathes from Anyang Xinsheng Machine Tool Co., Ltd. have the advantages of an advanced structure, good performance, convenient operation, and a neat and beautiful appearance. Specifically: The machine tool has a beautiful and elegant appearance, with a reasonable layout, compact structure, and is convenient for chip removal. The machine tool possesses…
Tool Clamping The length of the tool shank extending from the tool holder should not exceed 1.5 times the height of the tool shank (except for boring, grooving, etc.). The tool shank axis should be perpendicular or parallel to the feed direction. Adjustment of Tool Tip Height: For turning end faces, conical surfaces, threads, forming…
The oil level in the headstock must not be below the oil mark. Otherwise, the oil pump may suck in air, or the gear mist may be insufficient, causing spindle vibrations, excessive heating of the friction clutch and rolling bearings, and other issues. According to the lathe manual, all lubrication system oiling points must be…
Proximity of frequently used items: All items used during work should be placed as close as possible and concentrated around the operator’s area, but without hindering free movement. Frequency of use: Commonly used items should be placed closer, while rarely used items should be placed farther away. Natural movement: The placement of items must conform…
Types of lathes other than ordinary lathes and their characteristics and uses Ordinary lathe is the most widely used lathe, but in order to adapt to the processing needs of different types of workpieces, and derived from a variety of specialized lathes. They have their own focus in structure, function and application scenarios. 1. Specialized…
Machine Tool Description 1.1 Main Applications:This series of lathes is suitable for various turning operations, such as turning inner and outer cylindrical surfaces, conical surfaces, other rotary surfaces, and end faces. It can also cut various common threads — including metric, inch, module, and pitch threads — as well as perform drilling, reaming, tapping, and…
The CNC lathe consists of a spindle, slide, and tool post. The CNC system includes a display (CRT), a control panel, and a high-voltage control system. CNC lathes generally feature two-axis linkage: the Z-axis, which moves parallel to the spindle, and the X-axis, which moves perpendicular to the spindle in the horizontal plane. The latest…
On a lathe machine, the terms cutting depth (ap), S, and F are the three main cutting parameters you must know. 1. Depth of Cut (ap) Meaning: How deep the tool cuts into the workpiece in one pass. Unit: millimeters (mm). Typical values: Roughing (removing material fast) → 2–5 mm Finishing (for smooth surface) →…
Problem Analysis: Is the mechanical oil in the tank in compliance with the specifications stated in the machine’s user manual? Is the mechanical oil clean? Has the tank’s oil filter been cleaned regularly and the oil replaced as per the maintenance schedule in the user manual? Impurities or incorrect oil grade can cause the oil…
